เครื่องสแกนหน้า-ลายนิ้วมือ
UBio-X Pro

AC-6000

เครื่องสแกนลายนิ้วมือ

เครื่องสแกนลายนิ้วมือ / บัตร ประสิทธิภาพสูง

This state of the art terminal embraces the technology with a large color touch screen LCD, embedded digital camera and extremely fast processor.

AC-6000
AC-6000

คุณสมบัติ

1.3 Mega Pixel Digital Camera

Records a digital image of each user at the time of the transaction

5 inch Color TFT Touch Screen

Intuitive UI , simplifies operation User definable screen layout and background.

USB Memory

Transfers configuration settings, images, firmware and transaction logs using a USB Memory Stick.

Proximity Sensor

Recognizes the approach of a user and automatically turns on the LCD and keypad. Reduces power consumption.

การคอนฟิคระบบ

AC-6000 System Config

รายละเอียด

Model Name AC-6000
Authentication Method Face/Fingerprint/Card
Dust/Water Resistance X
Memory Max Users card (1:1) / (1:N) 100,000
Fingerprint
(Base on one finger enrollment per user)
1:1 100,000
1:N 30,000
Templates Fingerprint (1:1) 200,000
(1:N) 60,000
MAX Templates per Finger 2
MAX Finger per User 10
Logs 500,000
Images 12,500
Communication with server TCP/IP
Other USB
Wireless LAN(Wi-Fi) X
Wiegand OUT O
RS232 O
RS485 O
Wiegand IN O
Display LCD 5″Color Touch
Backlight O (With Motion Sensor)
Card 125khz-EM O
HID Prox X
HID iclass X
13.56MHz Smart Card O
Embedded Camera O
Keypad Touch Screen
Function keys 4+SOFT
Door Phone O
FP Sensor (Platen Area) 15 X 17 mm
Resolution 500 dpi
Dimension (W) X (H) X (D) mm 199.5 X 120.4 X 47
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
Opertating Software (Server solution) UNIS 4.5
