AC-5000 PLUS
Elegant Outdoor Fingerprint Authentication System
AC-5000 PLUS is a Premium outdoor fingerprint
recognition terminal with IP65 Dust & Waterproof.
ViRDI AC-5000 PLUS Premium Outdoor Fingerprint Recognition Terminal
(Dust & water proof, outdoor application, multi card reading)
ViRDI’s AC-5000 PLUS is an IP65 protection premium outdoor fingerprint terminal with a robust enclosure that is dust and waterproof. The multi-technology authentication system with fingerprint and multi-frequency card reading, AC-5000 PLUS supports up to 20,000 users per terminal.
Features
IP65 Dust & Waterproof
Ingress protected enclosure, keeping out dust moisture ensures faultless operation even under unfavorable conditions. Perfect for outdoor applications.
Live Finger Detection Technology
With our Live Finger Detection Technology,
It can distinguish fake fingerprint made from various materials
including gelatin, rubber, silicone, paper and more.
Support Multi Card Technology
AC-5000 PLUS features various multi-smart card support.
2.8inch Color LCD Screen
With its 2.8” Color LCD Screen it provides the user, wide and easy to use GUI.
Specification
| Model Name | AC-5000 Plus | |||
|---|---|---|---|---|
| Authentication Method | Fingerprint/Card | |||
| Dust/Water Resistance | IP65 | |||
| Memory | Max Users | card | (1:1) / (1:N) | 20,000 |
| Fingerprint (Base on one finger enrollment per user) |
1:1 | 20,000 | ||
| 1:N | 15,000 | |||
| Templates | Fingerprint | (1:1) | 40,000 | |
| (1:N) | 30,000 | |||
| MAX Templates per Finger | 2 | |||
| MAX Finger per User | 10 | |||
| Logs | 64,000 | |||
| Images | X | |||
| Communication | with server | TCP/IP | ||
| Other | X | |||
| Wireless LAN(Wi-Fi) | X | |||
| Wiegand OUT | O | |||
| RS232 | O | |||
| RS485 | OSDP | |||
| Wiegand IN | O | |||
| Display | LCD | 2.8″Color | ||
| Backlight | O | |||
| Card | 125khz-EM | O | ||
| HID Prox | O | |||
| HID iclass | O | |||
| 13.56MHz Smart Card | O | |||
| Embedded Camera | X | |||
| Keypad | O | |||
| Function keys | 10 | |||
| Door Phone | X | |||
| FP Sensor (Platen Area) | 16 X 20 mm | |||
| Resolution | 500dpi | |||
| Dimension | (W) X (H) X (D) mm | 88 X 175 X 43.5 | ||
| FRR /FAR | 0.1% / 0.0001% | |||
| Operating Temperature | -20 ~ 60℃ | |||
| Opertating Software (Server solution) | UNIS | |||
