AC-2000
Outdoor Fingerprint Recognition Terminal
AC-2000 is an Outdoor fingerprint recognition terminal with IP65 Dust & Waterproof.
Feature
IP65 Dust & Waterproof
Ingress protected enclosure, keeping out dust moisture ensures faultless operation even under unfavorable conditions. Perfect for outdoor applications.
Live Finger Detection Technology
With our Live Finger Detection Technology,
It can distinguish fake fingerprint made from various materials
including gelatin, rubber, silicone, paper and more.
Communicates through Bluetooth
With using Bluetooth, It supports the mobile card system.
Specification
| Model Name | AC-2000 | |||
|---|---|---|---|---|
| Authentication Method | Fingerprint/Card | |||
| Dust/Water Resistance | IP65 | |||
| Memory | Max Users | card | (1:1) / (1:N) | 10,000 |
| Fingerprint (Base on one finger enrollment per user) |
1:1 | 10,000 | ||
| 1:N | 1,500 | |||
| Templates | Fingerprint | (1:1) | 20,000 | |
| (1:N) | 3,000 | |||
| MAX Templates per Finger | 2 | |||
| MAX Finger per User | 10 | |||
| Logs | 51,000 | |||
| Images | X | |||
| Communication | with server | TCP/IP | ||
| Other | Bluetooth | |||
| Wireless LAN(Wi-Fi) | X | |||
| Wiegand OUT | O | |||
| RS232 | X | |||
| RS485 | OSDP | |||
| Wiegand IN | O | |||
| Display | LCD | X | ||
| Backlight | X | |||
| Card | 125khz-EM | O | ||
| HID Prox | O | |||
| HID iclass | O | |||
| 13.56MHz Smart Card | O | |||
| Embedded Camera | X | |||
| Keypad | X | |||
| Function keys | X | |||
| Door Phone | X | |||
| FP Sensor (Platen Area) | 14.8 X 17.9mm | |||
| Resolution | 500dpi | |||
| Dimension | (W) X (H) X (D) mm | 58 X 187.9 X 51.6 | ||
| FRR /FAR | 0.1% / 0.0001% | |||
| Operating Temperature | -20 ~ 60℃ | |||
| Opertating Software (Server solution) | UNIS | |||
